This equipment is designed for automated cutting and stacking of amorphous alloy cores, compatible with similar metal strip processing.

High Voltage Self-Aligning Winding Machine is suitable for winding coils of various small and medium-sized distribution transformers, instrument transformers, reactor coils, and similar processes. It consists of a winding mainframe, automatic wire alignment device, interlayer insulation device, pneumatically adjustable wire pay-off, pneumatic system, PLC control system, and servo system. Featuring high automation, comprehensive functionality, and robust power, it ensures the axial compactness and radial density of the wound coils.

This model integrates upgraded European/American design concepts, specifically engineered for precision foil winding in transformer and electrical industries. Supports single/double-layer winding and parallel winding processes, compatible with full-range copper/aluminum foil processing for high-capacity energy-efficient coils.

Designed for compact coil production in small/medium distribution transformers and similar applications. Achieves 20-30% volume reduction and 15-25% weight reduction in coils, lowering material costs and operational losses. Optimized insulation layout increases operational speed by 40% and reduces production interruptions by 60%, significantly boosting efficiency.

Designed for manufacturing coils in small/medium distribution transformers, instrument transformers, and reactors. Integrates winding, wire alignment, and insulation functions for multi-type precision coil production.

Designed for compact coil production in small/medium distribution transformers. Features dual-station synchronous winding for space-efficient manufacturing, optimized insulation layout, and energy-saving operations.

Upgraded with EU/US design concepts, this essential equipment is engineered for precision foil coil production in transformers and electrical industries. Supports single/double-layer winding and parallel winding processes, compatible with full specifications of 0.1-3.0mm Cu/Al foils for integrated HV/LV production.

Developed for small/medium distribution transformer coil manufacturing, this system integrates HV/LV processes for conventional coils, 3D wound core coils, and foil coils, meeting precision requirements for energy-efficient transformer core components.

Coil Shaping Press ZXYJ-100T

As an essential equipment for manufacturing low-capacity energy-efficient transformer coils, this machine is optimized based on proven manufacturing processes. Designed specifically for precision winding of single-layer foil coils, it supports fundamental specifications of copper/aluminum foil strip processing while meeting standardized production requirements in transformer and electrical component industries.

Designed for manufacturing compact coils in medium/large distribution transformers, instrument transformers, and reactors. Optimizes coil structure and production processes to reduce material costs and energy loss while enhancing manufacturing efficiency.
